MQTT Broker Load Testing: Benchmark Throughput and Latency

A broker that works with one test client can still fall over with a thousand devices. Load testing an MQTT broker answers three questions before production does: how many concurrent connections it accepts, how many messages per second it can route, and what latency your subscribers see while it is busy.

This guide shows how to plan a benchmark, run it with two open-source tools and a Python script, and read the numbers without fooling yourself.

What to measure

Always benchmark the same QoS, payload size and topic structure that your devices use. A test that publishes 10-byte QoS 0 messages to one topic says nothing about 2 KB QoS 1 telemetry spread over 50,000 topics. See MQTT QoS levels for how each level changes the packet count.

Pick the right target

Never run a heavy benchmark against a shared public sandbox — the numbers are meaningless (you are competing with every other user) and the operators will throttle or block you. Smoke-test there, then point the load at an instance you control.

For the examples below we use broker.connectmq.com; replace the host, port and credentials with your own instance.

1. emqtt-bench

emqtt-bench is an Erlang tool that can open tens of thousands of connections from one machine. The easiest way to run it is Docker:

docker run --rm -it emqx/emqtt-bench conn \
  -h broker.connectmq.com -p 1883 \
  -c 2000 -R 200 \
  -u "$MQTT_USER" -P "$MQTT_PASS"

Then measure throughput with a subscriber group and a publisher group running at the same time:

docker run --rm -it emqx/emqtt-bench sub \
  -h broker.connectmq.com -p 1883 \
  -c 100 -t 'bench/%i/#' -q 1

docker run --rm -it emqx/emqtt-bench pub \
  -h broker.connectmq.com -p 1883 \
  -c 100 -I 10 -t 'bench/%i/data' -s 256 -q 1

%i expands to the client index, so every publisher has its own topic and its own subscriber — a realistic one-to-one telemetry pattern. 100 publishers × 100 msg/s gives a target of 10,000 messages per second. emqtt-bench prints sent and received rates every second; if the received rate falls behind the sent rate, the broker (or your network) is the bottleneck.

2. mqtt-benchmark (Go)

If you prefer a single binary, mqtt-benchmark publishes a fixed number of messages and reports throughput and latency statistics:

go install github.com/krylovsk/mqtt-benchmark@latest

mqtt-benchmark \
  --broker tcp://broker.connectmq.com:1883 \
  --clients 50 --count 1000 --size 512 --qos 1 \
  --topic bench/go --format text

The summary at the end includes messages per second per client, the aggregate rate and mean / standard deviation of publish times — a quick way to compare two brokers or two configurations.

3. A latency script you can trust

Throughput tools measure how fast messages go in. Users feel how fast they come out. This Python script (paho-mqtt 2.x) embeds the send time in every payload and computes end-to-end percentiles on the subscriber side:

import json, statistics, time, uuid
import paho.mqtt.client as mqtt

HOST, PORT = "broker.connectmq.com", 1883
TOPIC = f"bench/{uuid.uuid4().hex[:8]}/latency"
N, RATE = 2000, 200          # messages, messages per second
samples = []

def on_message(client, userdata, msg):
    sent = json.loads(msg.payload)["t"]
    samples.append((time.perf_counter() - sent) * 1000)

sub = mqtt.Client(mqtt.CallbackAPIVersion.VERSION2)
sub.on_message = on_message
sub.connect(HOST, PORT)
sub.subscribe(TOPIC, qos=1)
sub.loop_start()

pub = mqtt.Client(mqtt.CallbackAPIVersion.VERSION2)
pub.connect(HOST, PORT)
pub.loop_start()
time.sleep(1)                # let the subscription settle

for i in range(N):
    pub.publish(TOPIC, json.dumps({"i": i, "t": time.perf_counter()}), qos=1)
    time.sleep(1 / RATE)

time.sleep(3)
samples.sort()
p = lambda q: samples[int(len(samples) * q) - 1]
print(f"received {len(samples)}/{N}")
print(f"p50 {p(0.50):.1f} ms  p95 {p(0.95):.1f} ms  p99 {p(0.99):.1f} ms  max {samples[-1]:.1f} ms")
print(f"mean {statistics.mean(samples):.1f} ms")

Because publisher and subscriber run in the same process, they share one clock — no NTP drift in the result. Run it once idle and once while emqtt-bench is hammering the broker: the difference is the latency your devices will see at peak.

Reading the results

• Received < sent at QoS 0 means the broker or the client dropped messages under pressure. Retry at QoS 1 to see whether it is a delivery or a capacity problem.
• p99 far above p50 points to garbage-collection pauses, disk-backed persistence or a saturated network link. Check broker CPU and the load generator's CPU — a maxed-out benchmark machine is the most common false result.
• Connection test stalls at a round number (1,024, 4,096, 65,535) — you hit a file-descriptor or ephemeral-port limit on the load generator, not the broker. Raise ulimit -n or spread the load across several machines or source IPs.
• Disconnects during the run — look for keep-alive timeouts or the broker's per-client inflight / queue limits. See MQTT keep alive and connection errors.

A repeatable load-test checklist

1. Smoke-test connectivity first with the online MQTT client or mosquitto_pub / mosquitto_sub.
2. Fix the scenario: number of clients, QoS, payload size, topic layout, retained or not.
3. Ramp up gradually (10 %, 50 %, 100 %, 150 % of expected peak) and hold each step for a few minutes.
4. Record broker CPU, memory and connection count next to the client-side numbers.
5. Repeat the run twice; only trust results that reproduce.
6. Re-run after every broker upgrade or configuration change.

Smoke-test the broker in your browser first

Load testing turns "it works on my laptop" into a number you can plan capacity around. Start small, measure latency where your users are, and keep the scripts in your repository so the next benchmark takes minutes instead of days.
