CircuitPython MQTT with MiniMQTT

Adafruit MiniMQTT (adafruit_minimqtt) is the MQTT client for CircuitPython. It runs on Wi-Fi boards like the ESP32-S2, ESP32-S3 and Raspberry Pi Pico W, uses the board's built-in TLS stack, and follows a callback style that will feel familiar if you have used paho-mqtt. This tutorial installs it, connects securely, publishes a reading every 10 seconds, reacts to commands and survives Wi-Fi drops.

The examples target CircuitPython 9.x with a current MiniMQTT release from the Adafruit bundle. Because CircuitPython reloads code.py each time you save, you can iterate quickly — and you will also see why a deployed device needs a real error-handling loop.

What you need

Install the library with circup, which copies the right .mpy files and dependencies to the CIRCUITPY drive:

pip install circup
circup install adafruit_minimqtt
circup list          # shows installed versions, flags outdated ones

You can also copy the adafruit_minimqtt folder from the library bundle into lib/ by hand; circup is less error-prone because it matches the bundle to your CircuitPython version.

1. Secrets in settings.toml

CircuitPython reads settings.toml from the root of the drive. The two CIRCUITPY_WIFI_* keys also make the board join Wi-Fi automatically at boot.

CIRCUITPY_WIFI_SSID = "your-ssid"
CIRCUITPY_WIFI_PASSWORD = "your-wifi-password"
MQTT_BROKER = "broker.connectmq.com"
MQTT_PORT = 8883
MQTT_USER = "username"
MQTT_PASS = "password"

Read them with os.getenv(). Keeping credentials here means code.py can be shared or committed without leaking anything.

2. A complete publisher and subscriber

import os, time
import microcontroller, ssl, socketpool, wifi
import adafruit_minimqtt.adafruit_minimqtt as MQTT

if not wifi.radio.connected:
    wifi.radio.connect(os.getenv("CIRCUITPY_WIFI_SSID"),
                       os.getenv("CIRCUITPY_WIFI_PASSWORD"))
print("Wi-Fi:", wifi.radio.ipv4_address)

DEVICE = "cpy-" + microcontroller.cpu.uid.hex()
BASE = f"testmqtt/cpy/{DEVICE}"

def on_connect(client, userdata, flags, rc):
    print("connected, rc =", rc)
    client.subscribe(f"{BASE}/cmd", qos=1)

def on_disconnect(client, userdata, rc):
    print("disconnected, rc =", rc)

def on_message(client, topic, message):
    print(f"{topic}: {message}")
    if message == "ping":
        client.publish(f"{BASE}/pong", str(time.monotonic()))

pool = socketpool.SocketPool(wifi.radio)
mqtt = MQTT.MQTT(
    broker=os.getenv("MQTT_BROKER"),
    port=os.getenv("MQTT_PORT"),
    username=os.getenv("MQTT_USER"),
    password=os.getenv("MQTT_PASS"),
    client_id=DEVICE,
    is_ssl=True,
    keep_alive=60,
    socket_pool=pool,
    ssl_context=ssl.create_default_context(),
)
mqtt.on_connect = on_connect
mqtt.on_disconnect = on_disconnect
mqtt.on_message = on_message
mqtt.will_set(f"{BASE}/status", "offline", retain=True, qos=1)

mqtt.connect()
mqtt.publish(f"{BASE}/status", "online", retain=True, qos=1)

last = 0
while True:
    mqtt.loop(timeout=1)                  # reads incoming packets, sends PINGREQ when due
    if time.monotonic() - last >= 10:
        temp = microcontroller.cpu.temperature
        mqtt.publish(f"{BASE}/temperature", f"{temp:.1f}")
        last = time.monotonic()

What the important lines do:

• socket_pool and ssl_context connect MiniMQTT to the board's network stack. ssl.create_default_context() uses the root certificates built into the CircuitPython firmware, so a broker with a certificate from a public CA verifies without extra files.
• loop(timeout=1) must run often. It processes incoming messages, calls on_message and sends keep-alive pings on schedule. The timeout must not be smaller than the client's socket_timeout (1 second by default), or MiniMQTT raises an error.
• Subscribing in on_connect means every successful connection — the first one and every reconnect — restores the subscription. This matters because shared test endpoints like broker.connectmq.com do not keep sessions between connections.
• microcontroller.cpu.uid gives a stable, unique client ID. If you prefer random IDs for throwaway tests, the client ID generator creates valid ones.
• microcontroller.cpu.temperature is a convenient demo value; on some boards it returns None. Swap in a real sensor driver (BME280, SHT4x, …) for actual readings.

Routing per topic

When a board subscribes to several topics, per-topic callbacks keep the code tidy:

def on_led(client, topic, message):
    led.value = message == "on"

mqtt.add_topic_callback(f"{BASE}/led", on_led)
mqtt.subscribe(f"{BASE}/led")

Messages on that topic go to on_led; anything else still reaches the general on_message.

3. Test it from the browser

Save code.py and open the serial console (Mu, Thonny or screen /dev/tty.usbmodem* 115200). You should see the IP address, then connected, rc = 0.

Now open the online MQTT client, connect to the same broker and subscribe to testmqtt/cpy/#. You will see the retained online status and a temperature every 10 seconds. Publish ping to testmqtt/cpy/<device>/cmd and a pong comes back within a second.

Watch your CircuitPython board in the browser

To test the Last Will, unplug the board: after roughly one and a half keep-alive periods, the broker publishes offline to the status topic.

4. Surviving disconnects

In development, an exception simply stops code.py and you fix it. On a device in a cupboard, an uncaught exception means it stays silent until someone power-cycles it. Wrap the loop:

def ensure_wifi():
    if not wifi.radio.connected:
        print("Wi-Fi reconnect")
        wifi.radio.connect(os.getenv("CIRCUITPY_WIFI_SSID"),
                           os.getenv("CIRCUITPY_WIFI_PASSWORD"))

delay = 1
last = 0
while True:
    try:
        mqtt.loop(timeout=1)
        if time.monotonic() - last >= 10:
            mqtt.publish(f"{BASE}/temperature", f"{microcontroller.cpu.temperature:.1f}")
            last = time.monotonic()
        delay = 1
    except (OSError, RuntimeError, ConnectionError, MQTT.MMQTTException) as e:
        print("error:", e, "- retry in", delay, "s")
        time.sleep(delay)
        delay = min(delay * 2, 60)
        try:
            ensure_wifi()
            mqtt.reconnect()              # on_connect runs again and resubscribes
            mqtt.publish(f"{BASE}/status", "online", retain=True, qos=1)
        except Exception as e2:
            print("reconnect failed:", e2)
            if delay >= 60:
                microcontroller.reset()   # last resort after repeated failures

The pattern is the same on every platform: fix the network layer first, then MQTT, back off exponentially so a fleet does not stampede a restarting broker, and keep a hard reset as the final safety net. MQTT reconnect best practices explains the reasoning in more depth.

5. TLS and certificate notes

• Public CA certificates just work. CircuitPython ships a root certificate bundle, and ssl.create_default_context() uses it.
• Self-signed or private CA? Load it explicitly: ctx = ssl.create_default_context(); ctx.load_verify_locations(cadata=CA_PEM) where CA_PEM is the PEM text of your root certificate.
• Memory is limited. TLS needs a sizable buffer. On boards without PSRAM, connect to MQTT early in code.py and avoid large allocations before the handshake.
• Plain TCP on 1883 works with is_ssl=False and port=1883, but sends the password in clear text. Use it only on a bench network.

If the handshake fails, rule out the broker side first with a TLS connection test from your computer.

Errors you will see

The CONNACK codes are the standard MQTT 3.1.1 return codes; the reason codes tool lists them all. For a sensor build that goes further — multiple sensors, JSON payloads, a dashboard — see the MQTT weather station. And if you are choosing between platforms, the MicroPython umqtt tutorial shows the same tasks with a lower-level client.

MiniMQTT gives CircuitPython boards a complete MQTT client with TLS in a few dozen lines. Put the secrets in settings.toml, subscribe in on_connect, call loop() constantly and wrap it all in a reconnect loop, and a hobby board becomes a device you can leave running for months.
