OwnTracks with Your Own MQTT Broker: Setup, TLS and ACLs

OwnTracks is an open-source location app for Android and iOS that can publish your phone's position straight to an MQTT broker. With your own broker you decide who sees the data, how long it is stored and which other systems (Home Assistant, Node-RED, a database) consume it. Setup takes four values in the app (host, port, username, password), plus TLS and an ACL on the broker side.

This guide covers the app settings, the topics and payloads OwnTracks uses, broker ACLs for sharing with friends, the OwnTracks Recorder, and how to verify each step from a terminal.

What you need

A public test broker is fine for checking that the app connects, but do not leave a real location stream on a shared endpoint: anyone who subscribes to owntracks/# there would see it.

Configure the app

In the app, open Preferences → Connection (Android) or Settings (iOS) and switch the mode from HTTP to MQTT. Field names differ slightly between platforms and versions, but the values are the same:

Save, then pull down on the map or tap the upload button to publish a location manually. The status screen should show the connection as connected. If you are not sure the broker accepts the credentials, test them first from your laptop with the online MQTT client — it isolates broker problems from app problems.

Topics and payloads

With username alice and device ID pixel, the app uses:

owntracks/alice/pixel          location messages (_type: location), retained by default
owntracks/alice/pixel/event    region enter/leave events (_type: transition)
owntracks/alice/pixel/info     card with name and avatar (_type: card)
owntracks/alice/pixel/cmd      commands TO the phone (_type: cmd)

A location message looks like this (fields abbreviated; exact fields depend on platform and version):

{
  "_type": "location",
  "tid": "AL",
  "lat": 48.856613,
  "lon": 2.352222,
  "acc": 12,
  "alt": 35,
  "batt": 78,
  "conn": "m",
  "t": "u",
  "tst": 1792236000
}

tst is the UTC time of the fix, acc the accuracy in metres, batt the battery level, conn the connection type (w Wi-Fi, m mobile) and t the trigger (u user, p ping, c region and others). The app also registers a Last Will message (_type: lwt) on the base topic, so a subscriber learns when the phone disconnects ungracefully.

The monitoring mode controls how often the phone reports: Significant (the default, battery-friendly, based on significant location changes), Move (frequent updates while moving, uses more battery), Manual and Quiet. Start with Significant.

If you build your own hardware tracker, publish the same JSON to the same topic layout and it shows up next to the phones. The GPS tracker tutorial builds one with an ESP32.

Verify from a terminal

Subscribe with the credentials of a user that may read Alice's topics:

mosquitto_sub -h broker.connectmq.com -p 8883 --capath /etc/ssl/certs \
  -u "$MQTT_USER" -P "$MQTT_PASS" -t 'owntracks/#' -v

Tap publish in the app; the JSON appears within a second or two. To test the reverse direction, ask the phone for a location with a remote command. Remote commands must be enabled in the app's advanced settings, and on iOS background delivery is not guaranteed:

mosquitto_pub -h broker.connectmq.com -p 8883 --capath /etc/ssl/certs \
  -u "$MQTT_USER" -P "$MQTT_PASS" \
  -t 'owntracks/alice/pixel/cmd' -q 1 \
  -m '{"_type":"cmd","action":"reportLocation"}'

You can also impersonate a phone to test the Recorder or a dashboard without walking around:

mosquitto_pub -h broker.connectmq.com -p 8883 --capath /etc/ssl/certs \
  -u "$MQTT_USER" -P "$MQTT_PASS" -t 'owntracks/alice/pixel' -q 1 -r \
  -m "{\"_type\":\"location\",\"tid\":\"AL\",\"lat\":48.8584,\"lon\":2.2945,\"acc\":10,\"tst\":$(date +%s)}"

ACLs: who sees whom

The app subscribes to owntracks/+/+ by default and draws every location it receives as a friend. That makes the broker's ACL the privacy control: a user sees exactly the topics they are allowed to read. In Mosquitto syntax:

# every user may publish and read under its own username
pattern readwrite owntracks/%u/#

# alice and bob share locations with each other
user alice
topic read owntracks/bob/#

user bob
topic read owntracks/alice/#

# the recorder reads everyone, publishes nothing
user recorder
topic read owntracks/#

On a managed broker you express the same rules as per-user topic permissions. Two details to remember:

• The username in the app must match the second topic level, otherwise every publish is denied. Many brokers drop a denied publish without disconnecting the client, so the phone looks connected but nothing arrives. See ACL denied silently.
• Test the rules from the outside: log in as Bob and try to read someone who has not shared with him. A short script for this is in testing MQTT ACL permissions.

Store history with the Recorder

The OwnTracks Recorder subscribes to the broker, stores every location on disk and serves a web map and an HTTP API. The Docker image is configured with environment variables:

docker run -d --name ot-recorder -p 8083:8083 \
  -e OTR_HOST=broker.connectmq.com \
  -e OTR_PORT=8883 \
  -e OTR_USER=recorder \
  -e OTR_PASS="$MQTT_PASS" \
  -e OTR_CAFILE=/etc/ssl/certs/ca-certificates.crt \
  -v ot-store:/store \
  owntracks/recorder

Open http://localhost:8083 for the Recorder's own web interface. Give the Recorder its own read-only user, as in the ACL above, and decide how long you keep history. Port 8083 here is the Recorder's HTTP port on your machine, unrelated to the broker's WebSocket port.

End-to-end encryption (optional)

OwnTracks can encrypt payloads with a shared secret key (libsodium). The broker then only sees {"_type":"encrypted","data":"…"} and every reader, including the Recorder, needs the key. It protects data from the broker operator, but you lose the ability to inspect messages in normal tools. TLS plus strict ACLs is enough for most setups; see MQTT payload encryption for the trade-offs.

Troubleshooting

OwnTracks on your own broker is one of the simplest useful MQTT deployments: a phone, one topic per device and a handful of ACL rules. Get TLS and the per-user permissions right first, verify each direction with mosquitto_sub and mosquitto_pub, and only then add the Recorder or home-automation integrations on top.
