MQTT from PowerShell on Windows

PowerShell has no built-in MQTT cmdlets, but there are two reliable ways to talk to a broker from a Windows script: call the mosquitto_pub / mosquitto_sub executables and treat their output as a pipeline, or load the MQTTnet .NET library straight into PowerShell 7. The first is perfect for one-liners, health checks and scheduled tasks; the second gives you a persistent connection and full control from a single .ps1 file.

This guide covers both, including the two traps that catch almost everyone — quotes disappearing from JSON payloads and event handlers that crash with "no Runspace available". All examples use broker.connectmq.com; keep the online MQTT client open to see the messages arrive.

Which approach?

If you end up writing more than a page of PowerShell around MQTTnet, a small C# console app is usually the better tool — see MQTT in C# with MQTTnet.

Option 1: mosquitto_pub and mosquitto_sub

Download the Windows installer from mosquitto.org. It installs the broker (you can skip the service) and the command-line clients into C:\Program Files\mosquitto. Add that folder to your PATH and test the connection:

$env:Path += ';C:\Program Files\mosquitto'     # current session only
$env:MQTT_USER = 'username'
$env:MQTT_PASS = 'password'

Test-NetConnection broker.connectmq.com -Port 1883 | Select-Object TcpTestSucceeded

mosquitto_pub -h broker.connectmq.com -u $env:MQTT_USER -P $env:MQTT_PASS `
  -t 'testmqtt/ps/hello' -m 'Hello from PowerShell' -q 1
"exit code: $LASTEXITCODE"

$LASTEXITCODE is 0 on success and non-zero when the connection or authentication fails, which is all a script needs. If TcpTestSucceeded is False, the problem is the network rather than MQTT — check whether the port is open and the Windows firewall. If you want to run a broker on the same machine, MQTT broker on Windows covers the service setup.

Sending JSON without losing the quotes

This is the most common PowerShell-specific MQTT bug. In Windows PowerShell 5.1 and PowerShell 7.0–7.2, embedded double quotes are stripped when arguments are passed to a native .exe, so the subscriber receives {device:pc-01} instead of valid JSON. PowerShell 7.3 fixed argument passing, but the robust solution works everywhere: build the object with ConvertTo-Json and pipe it into mosquitto_pub -s, which reads the message from standard input.

$payload = @{
  device = $env:COMPUTERNAME
  cpu    = (Get-CimInstance Win32_Processor | Measure-Object LoadPercentage -Average).Average
  ts     = (Get-Date).ToUniversalTime().ToString('o')
} | ConvertTo-Json -Compress

$payload | mosquitto_pub -h broker.connectmq.com -u $env:MQTT_USER -P $env:MQTT_PASS `
  -t "testmqtt/ps/$env:COMPUTERNAME/status" -q 1 -s

PowerShell adds a trailing newline when piping to a native program; JSON parsers ignore it. Use -l instead of -s to send every input line as a separate message.

Processing incoming messages in a pipeline

mosquitto_sub -v prints topic payload per line, and PowerShell turns each line into a pipeline object:

mosquitto_sub -h broker.connectmq.com -u $env:MQTT_USER -P $env:MQTT_PASS `
  -t 'testmqtt/ps/+/status' -v |
  ForEach-Object {
    $topic, $json = $_ -split ' ', 2
    $status = $json | ConvertFrom-Json
    if ($status.cpu -gt 90) {
      Write-Warning "$($status.device) CPU at $($status.cpu)%"
    }
  }

For a check that waits for exactly one message, add -C 1 -W 10: mosquitto_sub exits after the first message or after ten seconds, with a non-zero exit code on timeout. More flags are listed in mosquitto_pub and mosquitto_sub examples.

Option 2: MQTTnet inside PowerShell 7

MQTTnet is the most widely used .NET MQTT library. PowerShell 7 runs on modern .NET, so it can load the DLL directly. Download a 4.x package from NuGet and extract the netstandard2.0 build:

$version = '4.3.7.1207'                     # any MQTTnet 4.x version listed on nuget.org
$dir     = Join-Path $HOME 'mqttnet'
Invoke-WebRequest "https://www.nuget.org/api/v2/package/MQTTnet/$version" -OutFile "$env:TEMP\mqttnet.zip"
Expand-Archive "$env:TEMP\mqttnet.zip" -DestinationPath $dir -Force
$dll = Join-Path $dir 'lib\netstandard2.0\MQTTnet.dll'
Add-Type -Path $dll

Connecting and publishing work directly from PowerShell. Async methods return tasks, so call .GetAwaiter().GetResult() to wait for them (it also surfaces the real exception instead of an AggregateException):

$factory = [MQTTnet.MqttFactory]::new()
$client  = $factory.CreateMqttClient()

$options = [MQTTnet.Client.MqttClientOptionsBuilder]::new()
  .WithTcpServer('broker.connectmq.com', 1883)
  .WithClientId("testmqtt-ps-$env:COMPUTERNAME")
  .WithCredentials($env:MQTT_USER, $env:MQTT_PASS)
  .Build()

$none = [Threading.CancellationToken]::None
$connect = $client.ConnectAsync($options, $none).GetAwaiter().GetResult()
"connect: $($connect.ResultCode)"

$message = [MQTTnet.MqttApplicationMessageBuilder]::new()
  .WithTopic('testmqtt/ps/hello')
  .WithPayload('Hello from MQTTnet')
  .WithQualityOfServiceLevel([MQTTnet.Protocol.MqttQualityOfServiceLevel]::AtLeastOnce)
  .Build()

$result = $client.PublishAsync($message, $none).GetAwaiter().GetResult()
"publish: $($result.ReasonCode)"

The leading-dot method chaining requires PowerShell 7. A failed login throws an exception such as Connecting with MQTT server failed (BadUserNameOrPassword). or (NotAuthorized); the MQTT reason code lookup explains each value.

Receiving messages without the runspace crash

The obvious approach — $client.add_ApplicationMessageReceivedAsync({ ... }) — fails sooner or later with:

There is no Runspace available to run scripts in this thread.

MQTTnet raises the event on a .NET thread-pool thread, and a PowerShell script block can only run on a thread that owns a runspace. The clean fix is a few lines of C# that put each message in a thread-safe queue; your PowerShell loop takes them out on its own thread.

Add-Type -ReferencedAssemblies $dll -TypeDefinition @'
using System.Collections.Concurrent;
using System.Text;
using System.Threading;
using System.Threading.Tasks;
using MQTTnet.Client;
using MQTTnet.Protocol;

public static class MqttInbox
{
    public static readonly BlockingCollection<string[]> Messages = new BlockingCollection<string[]>();

    public static void Attach(IMqttClient client)
    {
        client.ApplicationMessageReceivedAsync += e =>
        {
            var seg  = e.ApplicationMessage.PayloadSegment;
            var text = seg.Array == null ? "" : Encoding.UTF8.GetString(seg.Array, seg.Offset, seg.Count);
            Messages.Add(new[] { e.ApplicationMessage.Topic, text });
            return Task.CompletedTask;
        };
    }

    public static MqttClientSubscribeResult Subscribe(IMqttClient client, string filter)
    {
        return client.SubscribeAsync(filter, MqttQualityOfServiceLevel.AtLeastOnce, CancellationToken.None)
                     .GetAwaiter().GetResult();
    }

    public static void Disconnect(IMqttClient client)
    {
        client.DisconnectAsync().GetAwaiter().GetResult();
    }
}
'@

[MqttInbox]::Attach($client)                       # attach before subscribing
[MqttInbox]::Subscribe($client, 'testmqtt/ps/#') | Out-Null
Write-Host 'Listening on testmqtt/ps/# - Ctrl+C to stop'

try {
  while ($true) {
    $msg = $null
    if ([MqttInbox]::Messages.TryTake([ref]$msg, 500)) {
      '{0,-35} {1}' -f $msg[0], $msg[1]
    }
  }
}
finally {
  [MqttInbox]::Disconnect($client)
  $client.Dispose()
}

The 500 ms timeout keeps the loop responsive to Ctrl+C, and the finally block sends a clean DISCONNECT so the broker does not fire a Last Will. Add-Type can define a type only once per session; running the script twice in the same console gives Cannot add type. The type name 'MqttInbox' already exists. — start a new pwsh session, or guard the call with if (-not ('MqttInbox' -as [type])).

Publish to testmqtt/ps/hello from the online client and the line should appear within a second.

Send a message to your PowerShell listener

TLS

Switch to port 8883 and enable TLS in the options builder. MQTTnet validates the broker certificate against the Windows certificate store, so a broker with a public certificate needs nothing else:

$options = [MQTTnet.Client.MqttClientOptionsBuilder]::new()
  .WithTcpServer('broker.connectmq.com', 8883)
  .WithTls()
  .WithClientId("testmqtt-ps-$env:COMPUTERNAME")
  .WithCredentials($env:MQTT_USER, $env:MQTT_PASS)
  .Build()

A scheduled heartbeat

Combining the pieces: a script that publishes machine status, and a scheduled task that runs it every five minutes.

$payload = @{
  device = $env:COMPUTERNAME
  freeGB = [math]::Round((Get-PSDrive C).Free / 1GB, 1)
  ts     = (Get-Date).ToUniversalTime().ToString('o')
} | ConvertTo-Json -Compress

$payload | mosquitto_pub -h broker.connectmq.com -p 8883 --cafile 'C:\mqtt\ca.pem' `
  -u $env:MQTT_USER -P $env:MQTT_PASS -t "testmqtt/ps/$env:COMPUTERNAME/status" -q 1 -s

if ($LASTEXITCODE -ne 0) {
  $line = '{0:o} mosquitto_pub failed with exit code {1}' -f (Get-Date), $LASTEXITCODE
  Add-Content -Path 'C:\mqtt\heartbeat.log' -Value $line
  exit $LASTEXITCODE
}

$action  = New-ScheduledTaskAction -Execute 'pwsh.exe' `
  -Argument '-NoProfile -NonInteractive -File C:\mqtt\heartbeat.ps1'
$trigger = New-ScheduledTaskTrigger -Once -At (Get-Date) -RepetitionInterval (New-TimeSpan -Minutes 5)
Register-ScheduledTask -TaskName 'MQTT heartbeat' -Action $action -Trigger $trigger

--cafile points to a PEM file containing the CA that signed your broker's certificate. Failures go to a log file, and the non-zero exit code shows up as the task's "Last Run Result" in Task Scheduler. The task above runs as you while you are logged in — for unattended servers, register it with a service account and store the credentials as that account's environment variables or with the SecretManagement module. Subscribe to testmqtt/ps/+/status to watch every machine report in.

Troubleshooting

PowerShell is a perfectly good MQTT client once you know its quirks: pipe JSON through stdin, check $LASTEXITCODE, and keep MQTTnet events on the .NET side of a queue. For the same automation on Linux, see MQTT in Bash scripts.

Frequently asked questions
