MQTT on Raspberry Pi: Sensors to Broker in 15 Minutes

Getting sensor readings from a Raspberry Pi into MQTT takes three pieces: a sensor library, the paho-mqtt client and a service manager that keeps the script alive. This tutorial wires a BME280 (or a DHT22) to a Pi, publishes temperature, humidity and pressure as JSON every 10 seconds, and runs the publisher as a systemd service that reconnects on its own and starts at boot.

Everything below was written for Raspberry Pi OS Bookworm (or newer) with Python 3.11+, paho-mqtt 2.x and the Adafruit CircuitPython sensor drivers. It works on a Pi Zero 2 W, Pi 3, Pi 4 and Pi 5.

What you need

Wire the BME280 to 3V3 (pin 1), GND (pin 6), SDA (pin 3, GPIO2) and SCL (pin 5, GPIO3). A DHT22 goes to 3V3, GND and a data pin such as GPIO4 (pin 7), with a 10 kΩ pull-up resistor if your module does not already include one.

You do not need a broker on the Pi. If you want one there anyway, see running a broker on Raspberry Pi; this article only covers the client side.

1. Enable I2C and check the sensor

sudo raspi-config nonint do_i2c 0
sudo apt update && sudo apt install -y i2c-tools python3-venv
i2cdetect -y 1

i2cdetect prints a grid. You should see 76 or 77 — that is the BME280's address. An empty grid means a wiring problem (SDA and SCL swapped is the classic one) or I2C is not enabled yet; reboot once after raspi-config if needed.

2. Create a virtual environment

Bookworm refuses system-wide pip install with error: externally-managed-environment. Use a venv in a project folder instead:

mkdir -p ~/sensors && cd ~/sensors
python3 -m venv .venv
.venv/bin/pip install paho-mqtt adafruit-circuitpython-bme280
# for a DHT22 instead:
# .venv/bin/pip install paho-mqtt adafruit-circuitpython-dht

The Adafruit drivers pull in Blinka, the compatibility layer that provides board and busio on Linux.

Quick sanity check before any MQTT code:

.venv/bin/python -c "import board; from adafruit_bme280 import basic as b; s=b.Adafruit_BME280_I2C(board.I2C(), address=0x76); print(s.temperature, s.relative_humidity, s.pressure)"

If you get ValueError: No I2C device at address: 0x76, try address=0x77.

3. The publisher script

The script below connects with a Last Will so subscribers know when the Pi drops off, publishes a retained online status, then sends one JSON reading every 10 seconds. Credentials come from environment variables so the same file works on your desk and in production.

import json, os, socket, time
import board
import paho.mqtt.client as mqtt
from adafruit_bme280 import basic as adafruit_bme280

HOST = os.getenv("MQTT_HOST", "broker.connectmq.com")
PORT = int(os.getenv("MQTT_PORT", "8883"))
DEVICE = socket.gethostname()
BASE = f"testmqtt/pi/{DEVICE}"
INTERVAL = 10

sensor = adafruit_bme280.Adafruit_BME280_I2C(board.I2C(), address=0x76)

def on_connect(client, userdata, flags, reason_code, properties):
    if reason_code.is_failure:
        print(f"connect failed: {reason_code}", flush=True)
        return
    print("connected", flush=True)
    client.publish(f"{BASE}/status", "online", qos=1, retain=True)

def on_disconnect(client, userdata, flags, reason_code, properties):
    print(f"disconnected: {reason_code}", flush=True)

client = mqtt.Client(mqtt.CallbackAPIVersion.VERSION2, client_id=f"pi-{DEVICE}")
client.username_pw_set(os.getenv("MQTT_USER"), os.getenv("MQTT_PASS"))
if PORT == 8883:
    client.tls_set()                      # system CA store
client.will_set(f"{BASE}/status", "offline", qos=1, retain=True)
client.reconnect_delay_set(min_delay=1, max_delay=60)
client.on_connect = on_connect
client.on_disconnect = on_disconnect

client.connect_async(HOST, PORT, keepalive=60)
client.loop_start()                       # network thread, retries until connected

while True:
    reading = {
        "temperature": round(sensor.temperature, 2),
        "humidity": round(sensor.relative_humidity, 1),
        "pressure": round(sensor.pressure, 1),
        "ts": int(time.time()),
    }
    info = client.publish(f"{BASE}/bme280", json.dumps(reading), qos=1)
    print(f"publish mid={info.mid} rc={info.rc} {reading}", flush=True)
    time.sleep(INTERVAL)

A few choices worth explaining:

• connect_async() + loop_start() — at boot the network may not be ready. connect() would raise immediately; connect_async() lets paho's background thread keep retrying, and the same thread reconnects after any later drop with the backoff set by reconnect_delay_set().
• QoS 1 for readings, so a brief outage does not silently lose data. paho queues QoS 1 messages while disconnected and sends them once the connection is back. QoS 0 would be lighter but drops anything sent during an outage.
• Retained status + Last Will — anything that subscribes later immediately sees online or offline. The pattern is explained in MQTT Last Will.
• Client ID from the hostname — stable and unique per Pi. Two devices sharing an ID will kick each other off the broker in a loop.

Using a DHT22 instead

The DHT22 protocol is timing-sensitive under Linux, so reads fail regularly with RuntimeError (for example "Checksum did not validate" or "A full buffer was not returned"). That is normal — skip the sample and try again:

import adafruit_dht
dht = adafruit_dht.DHT22(board.D4)

def read_dht():
    for _ in range(5):
        try:
            return {"temperature": dht.temperature, "humidity": dht.humidity}
        except RuntimeError:
            time.sleep(2)              # DHT22 needs ~2 s between reads
    return None                        # publish nothing this round

Call read_dht() in the main loop and only publish when it returns a value.

4. Test it by hand

Put the credentials in a file that only your user can read, then run the script in the foreground:

MQTT_HOST=broker.connectmq.com
MQTT_PORT=8883
MQTT_USER=username
MQTT_PASS=password

chmod 600 ~/sensors/mqtt.env
set -a; . ~/sensors/mqtt.env; set +a
.venv/bin/python publish.py

You should see connected followed by a publish mid=... line every 10 seconds. Now watch from another machine:

mosquitto_sub -h broker.connectmq.com -p 8883 --capath /etc/ssl/certs \
  -u "$MQTT_USER" -P "$MQTT_PASS" -t 'testmqtt/pi/#' -v

Or skip the install and open the online MQTT client in your browser, connect to the same broker and subscribe to testmqtt/pi/#. You will see the retained status message first, then a fresh bme280 JSON payload every interval.

Watch your Pi's readings in the browser

If nothing arrives, check the printed reason code. Bad user name or password and Not authorized are broker-side rejections; look them up in the MQTT reason codes tool. A timeout usually means the port is blocked — the connection errors guide walks through each case.

5. Run it as a systemd service

A script in an SSH session dies when you log out. systemd starts it at boot, restarts it if it crashes and collects its output in the journal.

[Unit]
Description=BME280 to MQTT publisher
Wants=network-online.target
After=network-online.target

[Service]
User=pi
WorkingDirectory=/home/pi/sensors
EnvironmentFile=/home/pi/sensors/mqtt.env
ExecStart=/home/pi/sensors/.venv/bin/python -u /home/pi/sensors/publish.py
Restart=always
RestartSec=5

[Install]
WantedBy=multi-user.target

Replace pi with your actual user name — recent Raspberry Pi OS images make you choose one at setup. The user must be in the i2c group (or gpio for a DHT22); the default user already is.

sudo systemctl daemon-reload
sudo systemctl enable --now bme280-mqtt
journalctl -u bme280-mqtt -f

-u on the Python command line disables output buffering so log lines appear in the journal immediately (the flush=True in the script does the same).

Prove it survives failures

1. sudo reboot — the readings should resume within a minute, with no SSH session open.
2. Unplug the network for a minute. Subscribers see offline once the broker notices the missing keep-alive (up to 1.5 × 60 seconds), then online again after reconnecting, followed by the readings queued during the outage.
3. sudo systemctl kill bme280-mqtt — systemd restarts the script after 5 seconds.

Where to go next

• Shape the payload for dashboards and databases: JSON payloads in Python.
• Add more sensors and a display: the MQTT weather station builds on this script.
• Feed Home Assistant by publishing discovery messages, covered in Home Assistant MQTT.

A Pi, a sensor and forty lines of Python are enough for reliable telemetry as long as the boring parts are handled: a venv for dependencies, a stable client ID, a Last Will for presence and systemd for restarts. Test each failure on your desk once, and the Pi in the garden will behave the same way.
