emqtt-bench Guide: Every Command and Flag Explained

emqtt-bench (the binary is called emqtt_bench) is an open-source MQTT benchmarking tool from EMQ, written in Erlang, that can open tens of thousands of connections and drive publish and subscribe load from a single machine. It has three commands — conn, sub and pub — and a long list of flags. This guide explains each command, the flags that actually matter, TLS and WebSocket usage, latency measurement and how to read what it prints.

For the broader method — what to measure and how to plan a benchmark — see MQTT broker load testing. This page is the reference for the tool itself.

Install or run with Docker

The quickest way is the Docker image, whose entrypoint is emqtt_bench:

docker run --rm -it emqx/emqtt-bench pub --help

For long or very large runs, a native install avoids Docker networking overhead. Prebuilt packages are published on the project's GitHub releases page. Building from source needs a recent Erlang/OTP and libatomic:

git clone https://github.com/emqx/emqtt-bench.git
cd emqtt-bench
make                      # BUILD_WITHOUT_QUIC=1 make if the QUIC build fails
./emqtt_bench conn --help

Before any benchmark, check the host, port and credentials by hand with one client in the online MQTT client. If one connection fails, two thousand will fail faster. The examples use broker.connectmq.com, a shared endpoint suited to quick checks; run real benchmarks against your own private broker instance by changing -h and the credentials.

Options shared by all commands

Two details trip people up. First, the default protocol version is MQTT 5; pass -V 4 to benchmark a broker or configuration that only speaks 3.1.1. Second, the keep alive default of 300 s is much longer than most devices use; set -k to your fleet's value if you are testing idle-connection behaviour.

Client IDs must be unique per broker. When you run several emqtt-bench processes against the same broker, give each its own --prefix or -n range — duplicate IDs cause session takeovers that look like random disconnects. You can preview ID formats with the client ID generator.

conn: connection capacity

conn only connects and holds the connections. It answers "how many concurrent clients can the broker hold, and how fast can it accept them?"

docker run --rm -it emqx/emqtt-bench conn \
  -h broker.connectmq.com -p 1883 \
  -c 5000 -R 500 -k 60 \
  -u "$MQTT_USER" -P "$MQTT_PASS"

Watch connect_succ climb to the target and connect_fail stay at zero. A reconnect storm — every device coming back after an outage — is simulated by raising -R. More scenarios are in the connection stress test guide.

sub: subscribers

sub connects clients and subscribes each one to a topic, then counts what it receives.

docker run --rm -it emqx/emqtt-bench sub \
  -h broker.connectmq.com -p 1883 \
  -c 100 -i 5 -q 1 \
  -t 'testmqtt/bench/%i/data' \
  -u "$MQTT_USER" -P "$MQTT_PASS"

pub: publishers

pub connects clients and publishes at a fixed interval per client.

docker run --rm -it emqx/emqtt-bench pub \
  -h broker.connectmq.com -p 1883 \
  -c 100 -I 100 -s 512 -q 1 -F 10 -w \
  -t 'testmqtt/bench/%i/data' \
  -u "$MQTT_USER" -P "$MQTT_PASS"

The target rate is clients × (1000 / -I). Note -F: with the default inflight window of 1, each QoS 1 client waits for every PUBACK before sending the next message, so at high latency a client can never reach its interval. If you see pub_overrun counting up, the client could not keep its schedule; raise -F or lower the rate. Throughput testing strategies are covered in the MQTT throughput test guide.

Topic placeholders

Placeholders in -t let one command create many distinct topics:

Using %i on both sides — pub -t 'testmqtt/bench/%i/data' and sub -t 'testmqtt/bench/%i/data' with the same -c — pairs publisher N with subscriber N: one-to-one routing. A single subscriber on testmqtt/bench/+/data instead measures fan-in, and many subscribers on one topic measure fan-out. Check your filters with the topic matcher.

TLS, WebSockets and QUIC

# MQTT over TLS
emqtt_bench conn -h broker.connectmq.com -p 8883 --ssl \
  --cacertfile /etc/ssl/certs/ca-certificates.crt \
  -c 1000 -R 100 -u "$MQTT_USER" -P "$MQTT_PASS"

# MQTT over secure WebSocket
emqtt_bench pub -h broker.connectmq.com -p 8084 --ws --ssl \
  -c 50 -I 1000 -t 'testmqtt/bench/%i/ws' -u "$MQTT_USER" -P "$MQTT_PASS"

emqtt-bench has no separate WebSocket path flag; the underlying emqtt client uses /mqtt, which matches the endpoint used throughout these examples. Comparing the same conn run over 1883 and 8883 shows the handshake cost directly — see MQTT TLS performance testing.

Measuring latency

Start the subscriber and the publisher with the same --payload-hdrs ts. The publisher writes a millisecond timestamp at the start of every payload; the subscriber subtracts it from its own clock on arrival:

# terminal 1
emqtt_bench sub -h broker.connectmq.com -c 50 -q 1 \
  -t 'testmqtt/bench/%i/lat' --payload-hdrs ts -u "$MQTT_USER" -P "$MQTT_PASS"
# terminal 2
emqtt_bench pub -h broker.connectmq.com -c 50 -I 200 -q 1 \
  -t 'testmqtt/bench/%i/lat' --payload-hdrs ts -u "$MQTT_USER" -P "$MQTT_PASS"

The subscriber then prints a publish_latency avg=…ms line. It is an average; for percentiles enable --prometheus (exposes an e2e_latency histogram) or use the script in the load testing guide. Because the timestamp comes from the publisher's clock, run both on one machine or keep the machines' clocks synchronized.

Reading the output

Every second, emqtt-bench prints one line per counter that changed, in the form <elapsed> <counter> total=<n> rate=<n>/sec:

10s connect_succ total=100 rate=0.00/sec
10s pub total=9871 rate=1000.12/sec
10s pub_succ total=9862 rate=999.40/sec

The healthy pattern: pub and recv rates match your target and each other, pub_overrun stays at zero, and no failure counters appear. A rising connection_timeout or connect_fail near a round number (1,024, 65,535) usually points to limits on the load generator. Look up any broker reason codes with the reason code tool.

Scaling the load generator

• File descriptors. Raise ulimit -n well above -c before large conn runs.
• Ports. One source IP can open only about 64K connections to one broker address and port. Use --ifaddr 10.0.0.11,10.0.0.12 or several machines, and widen the local port range with sysctl.
• Memory. Add -l for very large client counts at the cost of more CPU.
• CPU. If the generator is above roughly 80 % CPU, your numbers describe the generator, not the broker.

Watch benchmark traffic in the online client

emqtt-bench is the fastest way to put realistic connection and message load on an MQTT broker from the command line. Learn the handful of flags that shape the load — -c, -R, -I, -q, -F and the topic placeholders — confirm TLS and protocol versions match production, and read the counters as rates you can compare from run to run.
